mining lamp

This industrial high bay is an efficient, energy-saving and environmentally friendly lighting device, widely used in various scenarios.

Power

100/150/240W

Efficacy

150Lm/W

IP Rating

IP65-IP66

Product Introduction

This industrial high bay is an efficient, energy-saving and environmentally friendly lighting device, widely used in various scenarios. LED light beads deliver high energy efficiency and low energy consumption, significantly reducing energy consumption and operational costs. The lifespan is longer than that of traditional light sources, reducing the frequency of maintenance and replacement and lowering maintenance costs. It contains no harmful substances and is harmless to the environment, conforming to the concept of green environmental protection. LED industrial lighting fixtures adopt standard sizes and interfaces, making installation easy without special tools or skills.

Product Features

  • Energy saving and eco-friendly: LED light beads deliver low energy consumption and long lifespan, conforming to the concept of green environmental protection.
  • High safety: Unlike traditional light sources it generates no high temperature or electric sparks, improving safety in use.
  • High reliability: Solid-state encapsulated light beads are hard to damage and offer high reliability.

Main Application

Mainly applied to industrial plants, warehouses, waiting/boarding halls, exhibition centres, sports venues, etc.

Technical Specifications

Model numberXYXGKD-80W / XYXGKD-150W / XYXGKD-240W
Power100W / 150W / 240W
Size440*440*250mm / 465*465*300mm / 465*465*365mm
Input voltageAC100V-277V 50/60Hz
Drive power supplyMingwei, Philips, Maoshuo, Infineon, Xinzhaoyang
Chip configurationSMD3030 / SMD5050
Colour rendering indexCRI70 (CRI80 optional)
Luminous efficiency150Lm/W
Colour temperature3000K / 4000K / 5000K / 6000K
Lamp body materialAluminium alloy die casting
Protection levelIP65-IP66
Installation height15m-25m
Installation methodHooks, suspension rods, wall-mounted
